Product Description
Product Details:
Body Material | Metal |
Display Function | Animation,Graphics,Video |
Operating Voltage | 110-220 V |
Pixel | 3.9-16 mm |
Usage | Advertisements |
Brightness | 6500 cd/m2 |
Display Technology | Dot Matrix |
Lighting Color | Cool Daylight |
Numbers |
Technical indexes |
Specification |
1 |
Pixel pitch |
10mm |
2 |
Module size |
320mm×160mm |
3 |
Module resolution |
32×16 |
4 |
Module density |
10000dots/sqm |
5 |
Pixel configuration |
1R |
6 |
Red wavelength |
625±2nm |
7 |
Green wavelength |
525±2nm |
8 |
Blue wavelength |
470±2nm |
9 |
Colors |
red |
10 |
Best viewing distance |
10-120 m |
11 |
Horizontal viewing angle |
120° |
12 |
Vertical viewing angle |
70° |
|
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Body Material | Aluminum |
Operating Voltage | 110-220 V |
Brightness | 6500 cd/m2 |
Display Technology | Dot Matrix,Square Matrix |
Shape | Rectangle |
Lighting Type | LED |
Pixel Pitch | 10 mm |
Voltage | 220-240 V AC |
1. Solidness and safety is the first thing we think about
Every structure is approved by professional structural engineers
The global environment and climate always change.When you choose outdoor billboards,
the first consideration is safety. Qualified billboards should fully consider the following factors:
Strong winds, rain and snow, earthquake, thunderstorms, dry and wet environment and climate.
All those factors will have very big effect on materials’ physical and chemical properties .
BBD have considered everything for you and please rest assured.
2. Our products have advantages over other similar product
Safety: We stricly abide by design specifications and regulations by local government,making sure the safety of outdoor billboard.
Practical: The billboard structure is designed according to the human body engineering,making the worker's operation more safe,efficient and comfortable.Service doors of the billboard are equipped with dedicated anti-theft screw by independent research and development of BBD.
Beautiful: Various speficiations and types for you to choose,we also provide sample making service.
Numerical controlled machines make production more accurate and perfect.
Affordable: Digital design and management make full use of materials,reducing the cost.Precise calculation maximize the space value.Easy installation,less labor coat.
Eco-friendly and energy saving: Our products are hot dip galvanized and can be equipped with LED solar system to save resource.Besides all products can be disassembled and reused, which will reduce resource waste.
3. BBD can custom according to your sizes or any other demands.
We have standard size,but if your needing size is different from them.Don't worry,we can custom for you!
Or you have special requirements,also please feel free to contact us,we will design for you specially.
4. We have our own professinal structural designing team
Due to difference of regions,every product should meet different requirement.according to local geological condition, structure stype, load capacity and construction environment.
Advanced technology,reasonable price, safety and excellent quality are our requirements for products.
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Shape | Square |
Display Function | Video, Graphics, Animation |
Pixel Pitch | 3.9-16 mm |
Automation Grade | Automatic |
Tube Chip Color | Full color |
Viewing Angle | 120 Degree |
Body Material | Stainless Steel |
Ip Rating | IP65 |
What's the specification for Outdoor LED Display
Outdoor LED Display Specification | |||
Model number | P6.67 | P8 | P10 |
Pixel pitch | 6.67mm | 8mm | 10mm |
Module resolution | 48*48dots | 40 *40dots | 32*32dots |
Module size | 320x320mm | 320x320mm | 320x320mm |
Pixel Density | 27777 dots/sqm | 15625dots/sqm | 10000dots/sqm |
Brightness | ≥6500cd/sqm | ≥6500cd/sqm | ≥6500cd/sqm |
Weight | 20(kg/sqm) | ||
View angle | 140° | ||
LED configuration | 1R1G1B(SMD3IN1) | ||
Scanning | 1/6 | 1/6 | 1/2 |
Warranty | 2 Years quality warranty | ||
Grey Scale | 65536 level | ||
Working voltage | 200~240 V(50HZ/1500V(AC RMS)/1min) | ||
Life span | >100000 hours | ||
Temperature Range | work:-10???~+50???;storage:-40???~+85??? | ||
Certification |
CCC,ROHS,CE |
1.High brightness Contrast:4000:1, which is a very high level to ensure a vivid image of our LED display screen system
2. First-class LED chip to ensure the long lift-time and high brightness of our LED display screen system
What's the Advantage for Outdoor LED Display
How to control the quality?more than 48hours aging,moudle and screen
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Usage/Application | Advertising |
Brand | pixel |
Screen Dimensions | cutomized |
Humidity | 10-90% |
Display Technology | Dot Matrix |
Letter Height | 6 inches |
Display Function | Graphics, Video, Animation |
Use | Advertisement |
For Outdoor Pole Installation
High quality led lamp and mask for super bright display and high contrast image. 3. High Refresh Rate 1920Hz or 3840Hz refresh rate and constant current the colorful and stable playing effect. 4. Reliable Over 100,000 working hours for longtime use. 5. Multi-Control System Synchronous and asynchronour system for option. 6. Wide Usage Apply to shopping mall,cinema,banks,goods stores,airport,exhibition hall,streets,hospitals,squares etc. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Additional Information:
Product Details:
Usage/Application | advertisements |
Color | Full |
Installation Type | Fixed |
Display Size | customized |
Shape | Rectangle |
Brand | pixel |
Text Color | Full Colour |
Display Function | Video,Animation,Graphics |
1. Function and Technology Character
(1) Multiform file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB and so on are comprehensive.
(2) Information source can be camera, video, VCD, DVD, LD, TV and so on.
(3) Clear picture without flicker and distortion.
(4) Brightness, contrast, saturation can be adjust by itself and manual.
(5) Show everything with your PC does synchronously.
(6) Super correcting technology for distortion.
(7) One interface for sound signal and two for video signal at least.
(8) Connected and controlled by PC via Lan and remote control.
(9) Multiform language editions, such as English, French, Germany, Greek, Russian and so on.
Display and Control Feature | Structure Feature | ||
Specification | Parameter | Specification | Parameter |
Pixel Pitch | 8 mm | Module size | 256mm*128mm |
Pixel composing | 1R1G1B | Display resolution/module | 32 dots*16 dots |
Wavelength (R) | 625±5 | Standard cabinet size | 1024mm*768 |
Wavelength (G) | 522±3 | Weight per sqm | 45 Kg/sqm |
Wavelength (B) | 567±3 | Protection classification | --- |
Wave Angle (H) | 140°(H)/1400°(V) | Install mode | Wallmount, hung and stand structure |
LED package | SMD 0805 | SMD Type | SMD 3in1 & SMD 1in1 |
Density | 15,625 | Working Power | |
Display color | 256*256*256 | Specification | Parameter |
Whiteness brightness | ≥1100cd | Working voltage | AC 220v/380v±10% 47~64Hz |
|
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Usage/Application | Advertising |
Material | Die-cast alu |
Sign Board Type | video wall |
Lighting Type | king light |
Shape | Rectangular |
Color | full color |
Pixel Pitch | 6 mm |
Contrast Ratio | 169 |
Additional Information:
Product Details:
Usage/Application | Industrial |
Display Shape | Rectangle |
Screen Dimensions | customized |
Color | Red |
Lighting Color | Single color |
Mounting Type | Wall Mounted |
Body Material | Metal |
Active Screen Dimensions | Depends on user |
1)High Brightness, user can change the advertising words whatever you want, easy and convenient in operation, more attactive compared with traditional banner.
2) The multi-line led moving sign supports many kinds of languages and characters.
3) A lot of lively animation icons are built-in. 50 and more action effects for user option; Different brightness can be adjusted in software.
4) Time clock format, support date, countdown and any other odditional functions like temperature and humidity. Voltage input: 220v or110v.
5) multi-line led moving sign Structure: well appreance frame, professional pendents, standard connectors and other accessories.
Item | moving outdoor advertising led display screen |
Color | Red, green, blue,white/tri color/full color etc |
Module Size | |
Viewing Angle | 60~120° |
Service Access | Front or rear access |
Master/Slave | Single/Double/Three sides |
Casing Material | Aluminium Frame , Iron Cabinet |
Waterproof Level | IP53(Aluminium Frame) |
IP65(Iron Cabinet) | |
LED Driving mode | Static constant current |
Power Input | 110/220VAC , 60Hz/50Hz |
PC Communication | RS232 RS485 |
LAN(TCP/IP) | |
Communication Distance | Max.15meters for RS232, 1200meters for RS422 |
Remote control type | RF remote control (Standard) |
(RF wireless remote control with communication range of 100m.) | |
Lifetime of LEDs | > 100,000 Hours |
Working Temperature | -40°C to +50°C |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Usage/Application | Outdoor |
Display Function | Animation,Graphics,Video |
Display Technology | Dot Matrix,Square Matrix |
Font Styles Supported | Bold,Italic |
Display Shape | Rectangle |
Language Supported | English,Hindi,Urdu,Telugu,Tamil,Gujarati,Malayalam |
Usage | Advertisements |
Connectivity | Ethernet,RS232,RS485 |
Model number | 501 |
Product size | 440*93*15mm |
LED size | 420*83mm |
Pixel | 16*80 dot |
LED type | 3528SMD |
Voltage | DC 5-30V |
Power | 3-8W |
Installation | hanging / table stand / car mounted |
Program | bluetooth on Phone / USB key |
Color choice | red, green, blue, white, up and down mix color, right and left mix color, full color |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Shape | Rectangular |
Pixel Pitch | 3.9 - 16 mm |
Automation Grade | Automatic |
Tube Chip Color | Full color |
Operating Temperature | -5 to 65 Deg C |
Viewing Angle | 120 Degree |
Control System | Synchronization or asynchronous |
Brand | Quingli |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Square Feet |
Display Shape | Square,Rectangle |
Lighting Color | Single color |
Brand | pixel |
Usage/Application | Outdoor |
Active Screen Dimensions | Depends on user |
Model Number/Name | pixel06 |
Mounting Type | Wall Mounted |
Display Function | Video |
We offer our clients Big Screen P6 Waterproof SMD Rental Cabinet LED Advertising 6mm Video Panel Outdoor Large LED Screen at Competitive Prices across India.
Unit Module | Item | Parameter |
Model Number | cn-P6-8Scan | |
Module size | 192mm*192mm | |
Pixel pitch | 6mm | |
Pixels Density | 27777pcs/Square meters | |
Pixel configuration | 1R1G1B | |
Package mode | SMD3535 | |
Pixel resolution | 32dots(W)*32dots(H) | |
Max Power consumpion | 30W | |
Module thickness | 17mm | |
Weight | 0.8KG | |
Drive type | Constant drive | |
Scan mode | 1/8scan | |
Port type | HUB75 | |
Brightness of white balance | ≥5500cd/Square meters | |
bracket | Size | 192mm*192mm |
LED Unit Module | Dimension | 576mm*576mm |
Quanty of Module | 9 | |
Power supply | 5V/60A*1 pcs | |
Thermal discharge | fan 1pcs | |
Pixel per cabinet | 96*96 | |
Best viewing distance | 6M~10M | |
Best viewing distance | 140°(W) 120°(H) | |
Temperature | storage:-35???~+85??? working:-20???~+50??? | |
Opration humidity | 10%-95% | |
Thickness | 85mm | |
Power | Working voltage | AC220V±10% |
Average Power consumption | 260W/Square meters | |
Max.Power consumption | ≤800W/Square meters | |
Current | ≤20mA(single LED) | |
Control system | CPU | Pentium4 or above |
Operation system | WIN98/2000/NT/XP | |
Control method | Synchronization | |
Main technical parameter | Driving device | Constant currentdriver |
Refresh frequency | ≥400HZ | |
Grey scale/colors | 256levels of each color(RGB)/16.7M colors | |
MTBF | ≥9000hours | |
Power switch | Automatic switch | |
Display Mode | 800*600/1024*768 |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Display Technology | Dot Matrix |
Viewing Distance | 5 feet |
Language Supported | Urdu,Telugu,Tamil,Gujarati,English,Hindi |
Lighting Type | LED |
Usage | Advertisements |
Connectivity | Ethernet,RS232 |
Font Styles Supported | Bold,Italic |
Voltage | 220-240 V AC |
Features:1.Salt spray
2.Power- low consumption
Product Parameters
Name | Specification | Name | Specification |
LED Type | 3 IN 1 smd+lens | Pixel | p20 |
Module dimension | 320x160mm | Cabinet material | 2mm aluminum Alloy |
33mm round charooal | 33mm/40mm | brightness | L3,L3*EN12966 |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Usage/Application | advertisements |
Color | Full |
Installation Type | Fixed |
Display Size | 576mm*576mm |
Shape | Square |
Type | Outdoor Type |
Display Function | Video,Animation,Graphics |
Screen Dimensions | customized |
are the leading rental screen providing with comparative rates Waterproof Portable LED screen/Video wall Indoor/outdoor Led Screen, video wall, supplier on Rental, Hire, lease, and sale Indoor Rental LED Screen LED video dance floor and LED rolling curtainDisplay System Manufacturers, ,LED Scrolling Display Board Manufacturers, LED Mobile Hoarding Advertising Railway station led screen Advertising Agencies, Airport Advertising Agency, Outdoor Advertising ,Corporate Advertising Agency,Sign Board Advertising Agency, Traffic Sign Board ,Election Banner ,Electronic Display Board , Advertising Agencies For LED Screen,LED Screen Distributors,
Video Wall Dealers-NEC,LED Display Board ,Projector Screen Hire,Display Systems On Hire,LED Display Manufacturers,LCD Panels On Hire,TV On Hire,Plasma Display Screen ,Token Number Display System ,Plasma TV On Hire-Panasonic,Plasma Display Monitors On Hire,Display Digital,Plasma Display Installation,LED Walls On Hire,Plasma Display-Philips,
Floor stand Wall mount, Hangable, hanging, lift-able, curve and split-able led screen, used, second hand well maintained led scrren for sale, Silan , Nichia chip zdec, limson led manager software imported led screen for sale, rally campaign led screen , Delhi, Mumbai, Chandigarh, Banglore, Kolkata, Chennai,
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Color | Red |
Pixel Density | 10,000 Pixels/m2 |
Input Voltage | 220V |
Pixel Configuration | 1R1G1B |
Avg. Power Consumption | 350 W/m2 |
Max. Power Consumption | 800 W/m2 |
1:Support stretched LCD display and loop file when power on.;
2:Support video file:MP4,AVI,DIVX,DIVD,VOB,DAT,MPG,MPEG,RM,RMOV,HDMOV and so on.;
3:Support picture file:JPEG,BMP,GIF,PNG
4:Support audio file:MP3,WMA,OGG/AAC/AC3/DTS/FLAC/APE
5:Support VGA, DVI, HDM1, Ethernet , SD and U disk ;
6:Support USB updating function, it is more convenient for customers to change playing files;
7:Support Rolling text function
8:Support clock display;
9:Supports timer on/off, 5 segments each day, 7 days each week;
10:Support multi types of display effect and the interval time could be adjusted among 3s, 5s,10s and 20s;
11: Supports image rotation in 360 degrees
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Usage/Application | Advertising |
Material | Metal |
Lighting Type | king light |
Color | Full color |
Display Colors | full color |
Display Function | Animation, Graphics |
Pixel Pitch | 10 mm |
Brand | Quingli |
Electronic Big size Outdoor Advertising Waterproof P4.8 LED display/sign/screen
7500 nits brightness with 330W/sqm power consumption, 50% less than the traditional panels. Excellent display performance, the first option for millions of advertising operators.
1. Excellent visual effect, better viewing effect for text and graphic or video
2. Large viewing angle,both H/V can reach 110 degree;getting vivid effect within any position of the viewing range;
3. High contrast ratio and good evenness, high uniformity,without mosaic
4. Resist of the high temperature and antioxidation and anti-statiic;
5. Any led in each pixel can be respectively replaced, which reduce the cost of the display maintaince.
6. Long using life & MTBF
7.Fit for the outdoor fixed commercial applications such as shopping mall, mobile truck ,single/double pole mounted,wall mounted
Product Detail Photo
Product Highlights
Perfect display performance SMD provides wider viewing angles and extremely close viewing distances. |
|
|
Back-up System
Module double power and signal input, double insurance for working stability Still non-stop working in case of any failure.
|
IP65 Waterproof protection level
meeting the demands of various outdoor usage. |
|
|
Thin and light design Cabinet size:960*960*133mm ,31Kgs per panel, saving transportation cost. |
Standardized design
standardized module and cabinet for the FO Series,including P5,P6,P8 and P10 outdoor led display. reducing the delivery time and saving the maintenance cost for the advertisers. |
Application:
Widely used in Advertising media,Concert, TV SHOW,Super mall, Entertainment,School,Government,Trading conversation,Commodity fair,Exhibition,Cinema,News conferences, Meeting room,Airport,Hotel,Station Hall and other Public Places.
Item | P10 outdoor Full color LED module |
Pixel Pitch | 10m |
Pixel Configuration | DIP |
LED Type | 346 |
Module Size | 320 x 320mm / 160 x160mm |
Module Resolution | 32dots x 32 dots |
Module Weight | 1.03KG |
Grey Scale | 12 bit |
Refresh Rate | >1920Hz |
Scan Type | 1/4 Scan |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Square Feet |
Front brakes | Hydraulic |
Use | Advertisements |
Brightness | 6500 Cd/m2 |
Display Function | Animation |
Pixel Pitch | 3.9 - 16 mm |
Automation Grade | Automatic |
Tube Chip Color | Full color |
Life Span | 100000 hours |
P8 Indoor/Outdoor Full color LED display screen. | |
Module | PH 8 |
Module Size | 256*128mm |
Pixel Pitch | 8mm |
Pixel Configuration | 1R1G1B(in 3 n 1) |
LED Encapsulation | Black SMD 3535 |
Pixel Density | 15625dots /m2 |
Driver IC | Special constant current IC with high refresh rate & high grayscale |
Grey Scale | 14Bit(depending on the system and IC configuration) |
Cabinet Size | 512*512*66mm |
White balance Brightness | ≥1920cd/ m2 |
Viewing Angle | Horizontal 140°Vetical 120° |
Color Temperature | 8000K±500(adjustable) |
Optimal Viewing Distance | 8-50m |
Working Voltage | AC 220V/110V±10% |
Module voltage | DC4.2V |
Max Power Consumption | 80W/PCS |
Avg. Power Consumption | 40W/PCS |
Lifetime | ≥50000 hours |
Operating Temperature | –10~ 65 |
Net weight | 5Kg/pcs |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Usage/Application | advertisements |
Color | Full |
Lighting Type | LED |
Installation Type | Fixed |
Display Size | customized |
Types | Full color |
Shape | Square |
Brand | pixel |
LED ADVERTISING TRUCK SPEC.
Items | Descriptions | Specifications and Types |
General | Truck Name | LED Advertising Truck |
Drive Type | 4*2 | |
Gross Vehicle Weight(kg) | 7140 | |
Curb Weight (kg) | 5945 | |
Overall Dimensions L*W*H(mm) | 7450×2380×3350 | |
Engine | Engine Brand | Chaoyang |
Fuel Type | Diesel | |
Power | 92kw/125HP | |
Emission Standard | Euro IV | |
Displacement(ml) | 3900 | |
Engine Type | 4 cylinders in line,water cooling, super charged ,inter-cooling,diesel engine | |
Chassis | Chassis Brand | FOTON |
Truck Cab | Flat roof, single cab with A/C | |
Tire No. | 6 | |
Tire Specification | 7.50R16 Radial tire | |
Wheelbase (mm) ; | 3800 | |
Steering Wheel | Left hand drive | |
Gear Box | 5 speed forward with 1 reverse, manual | |
Brake | Oil brake | |
Radiator | Suitable for tropical climate | |
Screen | Left Side | P8 full color screen ,4800x2080mm |
Right Side | P8 full color screen ,4800x2080mm | |
Rear Side | P8 full color screen ,1600x1600mm | |
Remarks | 1.Details of the LED cabinets : 1) Equipped with DELI 25kw super silent generator 2) ACER computer console 3) Malata 2x60W water-proof column loudspeaker 4) high power amplifier 5) With A/C in LED cabinet 6) Interior light 7) Front cabinet with cooling fan and shutters 8) Pattern aluminum plate roof and high quality wood floor 9) 2 ventilation outlet on roof 10) 220V external power outlet, plug, power cord 11) Retractable step on rear door | |
2.One side of led screen can be lifted by hydraulic. Lifting height : 1.5m |
DETAILED VIEW OF TRUCK
Additional Information:
Product Details:
Usage/Application | Entertainments |
Color | Full |
Installation Type | Rental applications |
Display Size | 576mm*576mm |
Type | smd |
Display Type | customized |
Shape | Rectangle |
Brand | Leyard |
Indoor P4.81 500x500mm Rental LED Display
LED Module
1.LED Light Parameter
2.Pixel/Module
3.Screen Parameter
4.Cabinet :500x500mm
Product Details:
Minimum Order Quantity | 01 Square Feet |
Usage/Application | Advertisement |
Display Technology | Dot Matrix |
Color | Red |
Display Function | Animation,Graphics |
Pixel | 3.9-16 mm |
Lighting Color | Cool Daylight |
Shape | Rectangle |
Voltage | 220-240 V AC |
960mm*960mm Outdoor P10 Rental Led Display | |||
Item: | P10-4S | ||
Model Number: | 320mm*160mm | ||
Cabinet Size: | 960mm*960mm | ||
Pixel Pitch: | 10 mm | ||
Pixels Density: | 10000 dots/m² | ||
Pixel Configuration: | 1R1G1B | ||
Package Mode: | SMD3535 | ||
Pixel Resolution: | 64dots(W)*32dots(H) | ||
Drive Type: | Constant drive | ||
Scan Mode: | 1/4 scan | ||
Port Type: | HUB75 | ||
Brightness of White: | 7500cd/m² | ||
IP rate: | IP65/IP54 | ||
Input Voltage: | AC220V/110V,50HZ/60HZ (±10%) | ||
Output Voltage | 5V,60A | ||
Best Viewing Distance | ≥10m | ||
Refresh rate | 2000HZ | ||
Grey scale levels | R(256bit) x G(256bit) x B(256bit) | ||
Display Colors | R(1024) x G(1024) x B(1024) | ||
Working Temperature | -20~50???/10~90%RH | ||
Malfunction dot rate | < 0.0001 | ||
Life-span | 100,000 hours | ||
Warranty | 2 years | ||
Cabinet weight | 20kg | ||
Package: | Flight Case(3in1) size: 104*43*115cm; Gross weight:120kg |
Additional Information:
