sr no. | Item | Specification |
1 | Pixel Pitch | 6mm |
2 | Chip of LED | King star |
3 | LED per pixel | (SMD 3 in 1) |
4 | Resolution | 27777 pixle/sqm(uniformly spread over the surface, to ensure homogeneity) |
5 | LED Number per/sqm | 27777 |
6 | Single Module Dimension/Pixel(W x H) | 288 x 288 |
7 | Single Cabinet Dimension/Pixel(W x H) | 576 x 576 mm |
8 | Cabinet Material | Alluminium diecasting |
9 | Single Cabinet Weight | 10 kg Approx |
10 | Driver IC | MBI5124 |
11 | Power Supply | YMY (Original) |
12 | Best View Distancing | 6-100 m |
Product Details:
Minimum Order Quantity | 01 Piece |
Display Type | video |
Color | Full color |
Voltage | 5 V DC |
Power | 220 V AC |
Mounting Type | Plug-In |
Time Delay | <10 s |
Dimensions | 192mm*192mm |
Display Function | video |
No Of Inputs | 01 |
No Of Ports | 16 ports |
Non Waterproof | water proof |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Brightness | 6000 |
Best Viewing Distance | 10 meters |
Maximum Power Consumption | 100 watt |
Module Resolution | 192mm*192mm |
Voltage | 240 volts |
Type | Outdoor Type |
Shape | rectangle |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Color | full color |
Power | Ac 220 volts |
Voltage | 220 volts |
Shape | rectangular |
Size | 320mm*160mm |
Working Voltage | Ac 220 volts |
Operating Temperature | -20 To+80 |
Additional Information:
Product Details:
Usage/Application | Advertisements |
Mounting Type | Wall Mounted |
Brand | king light |
Type | Indoor |
Warranty | 3 Years |
Color | Full |
Power | Ac 220 volts |
Dimension | customized |
Text Color | Full Colour |
Lighting Type | LED |
Shape | Rectangle |
Display Technology | Dot Matrix |
Language Supported | English, Urdu, Gujarati, Punjabi, Malayalam, Telugu, Tamil, Hindi |
Led Lifetime | 100000 hours |
Connectivity | Wi-Fi, DSL/Cable Modem, Fiber Optics, Radio Frequency, RS485, Ethernet |
Operation Power Voltage | 220 |
Voltage | 220-240 V AC |
Viewing Angle | 140 |
Active Screen Dimensions | customized |
Power Source | Ac 220 volts |
Sound Type | Stereo |
Brightness | 1400 cd/m2 |
Model Name/Number | p4 mm |
Module Resolution | 64*32 |
Pixel Pitch | 4 mm |
Humidity | 90-100% |
Font Styles Supported | Bold |
IP Rating | IP 67 |
Body Material | Plastic |
Drive Ic | mbi5124 |
Protection | ip67 |
Module Size | 320*160mm |
Light | king light |
Software | nova star |
View Angle | 140 |
Working Temp | -20 To+80 |
Size/Dimension | 320mm*160mm |
Waterproof | Yes |
I Deal In | New Only |
pixel led ios leading suppilier of different types of indoor and outdoor led modules.
Product features
1. The first level LED chip from Taiwan Epistar.
2. SMD 2121 white pearl lamp
3. With pure golden wire connection in LED.
4. Ag alloy solder paster and copper plating thickness > 30mil on 4 layers PCB
5. All new stainless steel screws when assembly.
6. 2 years warranty.
Product specification
Model | LRPH-4 |
Pixel Pitch(mm) | 4 |
LED Configuration | 1RGB |
LED Type | SMD2121 |
Module Size(mm*mm) | 256x128 |
Module Resolution(PX*PX) | 64x32 |
Drive Mode | Constant Current Drive |
Scanning Mode | 1/16 |
Horizontal Viewing Angle(Deg) | 140 |
Vertical Viewing Angle(Deg) | 140 |
Brightness(cd/m2) | 1600cd |
Grey Scale | 16 Bits |
Refresh Rate(HZ) | 1200 |
Working Environment | Indoor |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Color | Full color |
Power | Ac 220 volts |
Voltage | 5v |
Type | Outdoor Type |
Shape | Rectangular |
Working Voltage | -20TO+60 |
Waterproof | yess |
Certification | bis |
Led Package | smd packaging |
Dimension | 320mm*160mm |
Price Range | 690 |
Grey Scale | 16340 |
Drive Ic | sm160 |
Brand | Qiangli |
Protection | ip67 |
Module Size | 320mm*160mm |
1, The price including P8 Led module, data cable and power cable(one power cable support 2pcs led modules)
2, The led module should be connect with LINSN, Novastar, Xixun etc Controller card.
3, We also offer complete led display screen.
Items |
Parameter |
Pixel Picth |
8mm |
Configuration |
1R1G1B |
Resolution |
15625dots/sqm |
Standard cabinet size |
768*768mm/960*960mm |
Cabinet material |
Iron or Aluminum |
Ave. Consumption |
400 w/sqm |
Max. Consumption |
1000 w/sqn |
Brightness |
More than 6000cd/sqm |
Grey Scale |
4096 |
View Distance |
8-100 m |
View Angle |
Horizontal: 140°, Vertical: 140° |
Power Supply |
AC 110V/220V+-10% |
Drive Mode |
1/4Scan |
Refresh Rate |
>1000 Hz/s |
Control System |
LINSN/NOVA |
Tolerance between modules |
≤0.5mm |
Storage Temperature |
- 35°C ~ + 75°C |
Working Temperature |
- 20°C ~ + 50°C |
Signal Interface |
DVI |
MTBF |
≥10,000 hours |
Life span |
≥100,000 hours |
|
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Color | Full color |
Power | 6 amp |
Voltage | Ac 220 volts |
Type | Outdoor Type |
Shape | Rectangle |
Size | 320*160mm |
Working Voltage | Ac 220 volts |
Operating Temperature | -20 To+60 |
Certification | bis |
Waterproof | waterproof |
Material | led module |
Led Package | smd |
Dimension | customized |
Price Range | 690-750 |
Grey Scale | 16340 |
Model Name/Number | p10 |
Usage/Application | Advertisements |
Drive Ic | sm16016 |
Brand | Qiangli |
Module Size | 320*160mm |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Color | Full |
Power | Ac 220 volts |
Voltage | 5v |
Type | Outdoor Type |
Shape | Rectangle |
Screen Dimensions | 320mm*160mm |
Display Function | Video |
Brand | p8 mm |
Pixel | p8mm |
Operating Temperature | -20 To+60 |
Display Technology | Square Matrix |
Model Name/Number | p8mm |
Waterproof | yess |
Module Resolution | 32*16 |
Weight | 0.5 kg |
Power Consumption | 200 watt per sq meter |
Dimension | 320mm*160mm |
Storage Temperature | -30To+80 |
Humidity | 90-100% |
Warranty | 3 Years |
Led Package | smd 3535 |
Drive Ic | sm16 series |
Mounting Type | smd |
Viewing Angle | 140 |
Life Span | 100000 |
Features of P8 outdoor led modules:
1. SMD3535 LEDS with glue,good waterproof IP65, long life span>100000hours
2. SMD led encapsulation confirm wide view angle and high brightness>6000nits
3. Dot-to-Dot maintainance, easy and quick maintain, save working time and cost
4. Low power consumption, low noise created, good environment protection
5. Can be used for fixed installation or for rental to meet the request of live broadcast, live meeting, banquet, party, etc, to display the content what you want, connect with PC computer or network, also can remoto control with asynchronous system.
Specification
Outdoor P8 SMD3535 LED Display | |
Pitch/mm | P8 |
Module size/mm | 320x160 |
Density of pixel/(dots/m2) | 15625 |
Pixel composition | 1R1G1B |
Led encapsulation | SMD3535 |
Resolution of module | 40x20 |
Optimum viewing distance | ≥8 |
View angle / ° | 140 H,120 V |
Average power consumption/W/M2 | 400 |
Max power consumption/W/M2 | 800 |
Size of cabinet/mm | 640x640/Customized |
Resolution of cabinet | 80x80 |
Weight of cabinet/kg | 8.4 |
Driving method | 1/4 scan constant current |
Refresh rate Hz/S | ≥60 |
Luminance of white balance | ≥6000 nits |
Operation of Environmental Temperature/°C |
below 30 to above 50 |
IP rating | Front,IP65;Rear,IP43 |
Working vlotage | 110-220 VAC/+/- 10% |
Grey scale/color | displaying colors≥16.7M(synchronized) |
Brightness adjustment | 256 levels of each color(manually), 100 levels of each color(automatically) |
Input signal | RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc |
Control system | Nova/Linsn(sending card,receiving cards and Hubs) |
Average of non-failure life | over 50,00h |
Life span | over 100,000h |
Functionaless dot rate | below 0.0001 |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Brand | pixel |
Part Number | p10 |
Power Dissipation | 200 watt per sq meter |
Type | Outdoor Type |
Screen Dimensions | customized |
Display Function | Graphics |
Pixel | 6mm |
Power Consumption | 200 watt per sq meter |
Voltage | 220-240 V AC |
Operating Temperature | -20 to +60 |
Storage Temperature | -30 To +80 |
Dimension | 192mm*192mm |
Module Size | 192mm*192mm |
Packaging Size | smd |
IP Rating | IP 67 |
Viewing Angle | 140 |
Cabinet | plastic body |
Life Span | 100000 |
Waterproof | Yes |
Model: | P6 outdoor | P8 outdoor | P10 outdoor | P16 outdoor |
Pixel pitch | 6mm | 8mm | 10mm | 16mm |
LED Type | SMD3535 | SMD3535 | DIP346 | DIP346 |
Scan Styple | 1/8 scan | 1/4 scan | 1/4 scan | Static |
Resolution | 27,777 pixels/sqm. | 15,625 pixels/sqm. | 10,000 pixels/sqm. | 3906 pixels/sqm. |
Module size(mm) | 192*192mm | 256*128mm | 160*160mm | 256*256mm |
Panel Size(mm) | 768 mm*768 mm | 1024*768mm | 960 W*960 H | 1024*1024mm |
Refresh rate | >2000Hz | >2000Hz | >2000Hz | >2000Hz |
Brightness | >6000Nits | >6000Nits | >7500Nits | >7500Nits |
Max Power/ sqm | 1000W | 1000W | 750W | 1000W |
Weight per sqm (Iron cabinet) | about 50Kg | about 50Kg | about 55Kg | about 55Kg |
Best viewing distance | ≥6m | ≥8m | ≥10m | ≥10m |
Cabinet material | Waterproof Iron cabinet or waterproof aluminum cabinet | |||
Operating temperature | -30ºC----+60ºC | |||
Operating humidity | 10%---??RH | |||
Operating system | Windows XP / Windows 7 / Windows 8 / 8.1 / Windows 1 |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Usage/Application | Advertising |
Mounting Type | Wall Mounted |
Model Name/Number | p4.8 mm |
Active Screen Dimensions | Depends on user |
Lighting Color | full color |
Brand | king light |
Shape | Rectangle |
Display Function | Animation, Video, Graphics |
Sound Type | Stereo |
Pixel | 4.8 mm |
Module Pixels | 40*40 |
Display Shape | Square |
Driving Method | Synchronization or asynchronous |
Connectivity | Ethernet, DSL/Cable Modem, Radio Frequency, RS485, Wi-Fi, Fiber Optics |
Light | king light |
Display Technology | Square Matrix |
Working Voltage | Ac 220 volts |
Font Styles Supported | Bold |
Voltage | 220-240 V AC |
Led Package | smd packaging |
Frequency | 60 Hz |
Cabinet Resolution Dot | 40*40 |
Dimension | customized |
Cabinet Weight | 0.5 kg |
Brightness | 6500 cd/m2 |
Module Resolution | 40 *40 |
Pixel Pitch | 4 mm |
Viewing Angle | 140 |
Power Consumption | 200 watt per sq meter |
Language Supported | Punjabi, Hindi, Tamil, Malayalam, Telugu, English, Urdu, Gujarati |
Storage Temperature | -20 to +60 |
Humidity | 90-100% |
Warranty | 3 Years |
IP Rating | IP 67 |
Color | Full Colour |
I Deal In | New Only |
Waterproof | Yes |
SMD led display outdoor/ p4.8 led display modules/ backdrop video wall.
pixel led is leading suppilier of different types of indoor and outdoor led modules at very affordable prices.
Product Description
Application filed:
Advertising LED displays, stage led screens, mobile led display for mobile media, led video walls outdoor events deocr, led video wall controller for Music concerts, touring& festival, cooperate parties and so on.
LED Standard parameter
Aluminum Rental Outdoor LED Display Screen |
||
Module |
Pitch/mm |
P4.81 |
|
Module size/mm |
250x250 |
|
Density of pixel/(dots/m2) |
43,264 |
|
Pixel composition |
1R1G1B |
|
Led encapsulation |
SMD2727 |
|
Resolution of module |
52x52 |
|
Optimum viewing distance |
≥4-10m |
Main |
View angle / ° |
160 H,140 V |
|
Average power consumption/W/M2 |
260 |
|
Max power consumption/W/M2 |
520 |
|
Size of cabinet/mm |
500x1000x75mm |
|
Resolution of cabinet |
104*208 |
|
Weight of cabinet/kg |
10 |
|
Driving method |
1/13 scan constant current |
|
Frame frequency / Hz/S |
≥60 |
|
Refresh rate Hz/S |
≥1000 |
|
Luminance of white balance |
≥5500 nits |
|
|
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Color | Full |
Power | Ac 220 volts |
Voltage | Ac 220 volts |
Type | Indoor Type |
Shape | Rectangle |
Text Color | Full Colour |
Active Screen Dimensions | customized |
Usage/Application | Advertisements |
Operational Temperature | -20 To +60 |
Brand | king light |
Driving Method | 1/2 scan |
Led Configuration | smd 2121 |
Led Lifetime | 100000 hours |
Waterproof | yes |
Viewing Angle | 140 |
Scanning Mode | 1/2 |
Power Consumption | 200 watt per sq meter |
Connectivity | DSL/Cable Modem, Ethernet, RS485, Wi-Fi, Radio Frequency, Fiber Optics |
Frequency | 60 Hz |
Dimension | 192mm*192mm |
Humidity | 90-100% |
Warranty | 3 Years |
Font Styles Supported | Bold, Italic |
Led Package | smd 2121 |
Language Supported | Telugu, Tamil, Hindi, English, Punjabi, Malayalam |
Drive Ic | mbi5124 |
Protection | ip67 |
Lamp | king light |
Lifespan | 100000 hours |
Scan Mode | 1/2 scan |
PH3 indoor led module technical parameter list
Model number | PH3 |
Pixch pitch | 3mm |
Pixel Density(dots/m2) | 111111 |
Pixel Configuration | SMD2121 3 IN1 |
Module size (mm) | 192*192 |
Module resolution (dots) | 64*64 |
Scanning method | 1/32 |
Brightness (cd/m2) | 4000 |
Min. viewing distance | ≥2 |
Viewing angle ( 50% brightness ) | ≤150° |
Screen fresh rate | LED screen refresh frame freauency recommended is no less than 1200HZ(recommended) |
Average Power Consumption(w/m2) | 800 |
IP grade ( Waterproof Grade ) | IP31 |
Module thickness | 1.5cm |
Control system | LINSN , Nova ,HD , XIXUN..... |
Input Voltage | AC220 V/50HZ or AC 110V/60HZ |
Gray Scale | Recommended 14bit |
Printed Circuit Board(PCB) | 4 Layer |
Color Temperature | The brightness of R.G.B.is adjustable according to software 100level;Color temperature is adjustable in terms of detailed requirements |
Color | 64g color(on the condition of 4096 gray scale) |
Effective Communication Distance(without relay) | Unshielded twisted-pair net line transmission distance is 100 meters,max transmission distance is 130 meters. |
Module weight | 0.4KG/PCS |
Warranty |
3 years |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Color | Red |
Shape | rectangular |
Size | 320MM*160MM |
Working Voltage | Ac 220 volts |
Operating Temperature | -20To +80 |
Certification | bis |
Led Package | dip |
Model Name/Number | p10 single color |
Usage/Application | Advertisements |
Brand | Qiangli |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Color | Full color |
Power | Ac 220 volts |
Voltage | 220 volt |
Type | Outdoor Type |
Shape | rectangular |
Size | 320mm*160mm |
Working Voltage | Ac 220 volts |
Operating Temperature | -20To+80 |
Certification | bis |
Waterproof | yes |
Led Package | smd 3535 |
Dimension | 320mm*160mm |
Grey Scale | 16340 |
Drive Ic | mbi 5124 |
Brand | king light |
Module Size | 320mm*160mm |
Module parameters | |
Model | P10 |
Pixel pitch | 10mm |
Pixel configuration | 1R1G1B |
Pixel matrix per panel | 32*16 pixels |
Module resolution rate | 32*16=512dots |
Module dimensions (W*H*D) | 320*160*26.0mm |
Weight | 1.0kg±0.05kg |
Package material | Polycarbonate |
Construction | combined driver board |
Input votage | 4.5-5.5V |
MAX. input current | 5.4A±0.1A |
Driving mode | 1/16 scan, constant current |
Module power | ≤27 W |
Cabinet parameters | |
Brightness | ≥6500 cd/m2 |
Standard cabinet dimensions (W×H×D) | 960*960*200 mm |
Resolution | 96*96=9216dots |
Weight | 37.5±0.05 kg |
Pixel density | 10000 dots/m2 |
Viewing angle (H/V) | 105±8°,50±10° |
Best viewing distance | ≥10m |
MAX. power | ≤750W |
Control parameters | |
Gray scale per color | 12-16bits for red,green,blue |
Colors | 16777216 |
Life time | ≥100,000 hours |
MTBF | ≥10,000 hours |
Refresh rate | ≥ 480Hz |
Input voltage (AC) | 110V ~ 240V |
Operating temperature | -20°C ~+ 50°C |
Operating humidity | 10% ~ 90% |
Source compatibility (with video processor) | DVI/VGA,Vedio(mutiple modes),RGBHV,composite Vedio Single,S-VIDEO,YpbPr(HDTV) |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Installation Type | Fixed |
Display Size | 192*192mm |
Types | led display |
Color | Full |
Power | Ac 220 volts |
Voltage | Ac |
Type | Indoor Type |
Shape | Rectangle |
Text Color | Full Colour |
Active Screen Dimensions | customized |
Usage/Application | Advertisements |
Brand | king light |
Driving Method | 1/2 scan |
Led Configuration | smd 2727 |
Led Lifetime | 100000 hours |
Access | online/offline |
Waterproof | yes |
Viewing Angle | 140 |
Warranty | 3 Years |
Led Package | smd |
Font Styles Supported | Italic, Bold |
Language Supported | Gujarati, Urdu, English, Tamil, Malayalam, Punjabi, Telugu, Hindi |
Drive Ic | mbi5124 |
Hdmi | yes |
Mounting Type | smd mounting |
Module Size | 288mm*288mm |
Packaging Size | 40 |
Max Power Consumption W Per Square M | 200 watt per sq meter |
Module Size Mm | 288 mm*288 mm |
Body Material | Metal |
Power Supply | 220 volts |
I Deal In | New Only |
is strong, light, easy to remove and reinstall. Better for rental use.
Iron Cabinetis strong, light, can be assembled firmly tight. Better for fixed use.
Magnet Assembleattach the module to the cabinet or to the iron frame for easy and fast assemble and remove.
Screw Assemblefasten the module to the iron frame firmly and crackless.
Product ShowAdditional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Color | Full |
Power | Ac 220 volts |
Voltage | Av 220 volts |
Type | Indoor Type |
Shape | Rectangle |
Lighting Type | LED |
Text Color | Full Colour |
Active Screen Dimensions | customized |
Usage/Application | Advertisements |
Brand | king light |
Driving Method | 1/2 scan |
Brightness | 6500 cd/m2 |
Operating Temperature | -20 To+80 |
Led Configuration | smd 2727 |
Display Technology | Square Matrix, Dot Matrix |
Led Lifetime | 100000 hours |
Specification Paramter
Item name |
P4 |
Pixel pitch |
4mm |
Module size(W*H) |
256*128mm |
pixels Density |
62500 dots/sqm |
Pixel configuration |
SMD1921 |
Classification |
Full color |
Pixel resolution |
64*32 dots |
Cabinet size |
512mm*512mm |
Quantity of Module |
8pcs |
Cabinet Weight |
8KG |
Best viewing distance |
4-- 50m |
Best viewing angle |
140°(H) /140°(V) |
Temperature |
storage: - 30°C~+ 70°C |
|
working: '- 20°C~+ 50°C |
Working voltage |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Color | Full |
Power | Ac 220 volt |
Voltage | 5v |
Type | Outdoor Type |
Shape | Rectangle |
Display Function | Animation, Graphics, Video |
Active Screen Dimensions | customized |
Sound Type | Stereo |
Brand | king light |
Pixel | 3mm outdoor |
Operating Temperature | -20 To+80 |
Driving Method | Synchronization or asynchronous |
Waterproof | yes |
Light | king light |
Working Voltage | 220 |
Brightness | 4000 cd/m2 |
Contrast Ratio | 169 |
Scan Mode | 1/2 |
Frequency | 60 Hz |
Humidity | 90-100% |
Warranty | 3 Years |
Font Styles Supported | Italic, Bold |
Led Package | smd 2121 |
Language Supported | Punjabi, Hindi, Telugu, Urdu, Malayalam, English, Gujarati, Tamil |
Drive Ic | mbi5124 |
Module Size | 288mm*288mm |
View Angle | 140 |
Additional Information:
Product Details:
Minimum Order Quantity | 1 Piece |
Usage/Application | Advertising |
Color | Full |
Power | Ac 220 volts |
Voltage | 5v |
Type | Outdoor Type |
Shape | Rectangle |
Active Screen Dimensions | customized |
Installation | Done by our Team |
Brand | pixel |
Character Size | variable |
Display Technology | Square Matrix |
Waterproof | yes |
Model Name/Number | p5 |
Viewing Angle | 140 |
Weight | 0.5 kg |
Power Consumption | 200 watt per sq meter |
Connectivity | RS485, Fiber Optics, Ethernet |
Frequency | 60 Hz |
Dimension | customized |
Storage Temperature | -20 to +60 |
Humidity | 90-100% |
Price Range | 1500 |
Warranty | 3 Years |
Led Package | smd |
Font Styles Supported | Bold |
Language Supported | Punjabi, Gujarati, Urdu, Hindi, Tamil, Telugu, Malayalam, English |
Drive Ic | mbi5124 |
Protection | ip 65 |
Mounting Type | smd mounting |
Life Span | 100000 hours |
Text Color | Full Colour |
pixel led is leading suppiler of different types of indoor and outdoor types led display modules at very affordable prices and quality is also good.
Product features
1. The first level LED chip from Taiwan Epistar.
2. SMD 2121 white pearl lamp
3. With pure golden wire connection in LED.
4. Ag alloy solder paster and copper plating thickness > 30mil on 4 layers PCB
5. All new stainless steel screws when assembly.
6. 2 years warranty.
Product specification
Model | LRPH-5 |
Pixel Pitch(mm) | 5 |
LED Configuration | 1RGB |
LED Type | SMD2121 |
Module Size(mm*mm) | 320x160 |
Module Resolution(PX*PX) | 64x32 |
Drive Mode | Constant Current Drive |
Scanning Mode | 1/16 |
Horizontal Viewing Angle(Deg) | 140 |
Vertical Viewing Angle(Deg) | 140 |
Brightness(cd/m2) | >1200cd |
Grey Scale | 14 Bits |
Refresh Rate(HZ) | 1200 |
Working Environment | outdoor |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Warranty | 3 Years |
Type | Indoor |
Brand | king light |
Color | Full |
Power | Ac 220 volts |
Usage/Application | advertisements |
Mounting Type | Wall Mounted |
Dimension | customized |
Text Color | Full Colour |
Operating Temperature | -20 To+80 |
Shape | Rectangle |
Language Supported | Urdu, Tamil, Hindi, Gujarati, Malayalam, English, Telugu |
Led Lifetime | 100000 hours |
Connectivity | DSL/Cable Modem, RS485, Fiber Optics, Ethernet, Radio Frequency, Wi-Fi |
Viewing Angle | 140 |
Voltage | 220-240 V AC |
Color Of Display | Full color |
Active Screen Dimensions | customized |
Sound Type | Stereo |
Power Source | Ac 220 volts |
Brightness | 6500 cd/m2 |
Weight | 0.5 kg |
Power Consumption | 200 watt |
Led Package | smd 1515 |
IP Rating | IP 67 |
Waterproof | Yes |
I Deal In | New Only |
Setting Information | |
Pixel pitch | 2 mm |
Density | 250000dots/sqm |
LED Type | SMD2020/SMD2121black |
Module size | 192*96mm |
Cabinet size | According to the project |
Cabinet material | Die-casting Aluminum/Steel/Iron |
Brightness | 1000nits |
Warranty Item | 2 years quality guarantee |
Minimum Viewing Distance | 2 meters |
Viewing Angle | Horizontal :140° Vertical??? 140° |
Gray scale | 14bit level |
Refresh frequency | ≥1200HZ |
Driving mode | 1/32 scan constant current driving |
Input power frequency | 50 or 60 Hertz |
Input Voltage | 110/220 Volt |
Blind spot rate | ???1/10000 |
Lifetime at 50% brightness | ≥100000 h |
Ingress Protection | IP31 Rating |
Operating temperature | ???20 ??????50 ??? |
Operating humidity | 10??? ??? 90??? |
Control distance | CAT5 cable:???100 m; Single mode fiber:???10 km |
Control system | Linsn , Novastar, Huidu, Sheenled, Colorlight etc |
Control method | Synchronous, Asynchronous, Wifi, 3G/4G wireless control |
Certifications | CE,ROHS,FCC etc |
1. P2 HD indoor LED video wall modules, with the date&power cables;
2. LED modules can work with Nova, Linsn, Colorlight,Xixun LED Conrol Card ,etc.
3. High precision module suite, to achieve high-quality seamless effect.
4. High quality LED lamp black, with a black mask, the contrast up to 3000: 1.
5. High gray,up to 16bit gray scale in low-light display gray scale performance is still intact.
6. High refresh rate,the display is stable, no ripples, no flicker, display real and natural.
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Color | Full |
Power | Ac 220 volts |
Voltage | 220 volts |
Type | Outdoor Type |
Shape | Rectangle |
Brand | pixel |
Operating Temperature | -20 To +60 |
Waterproof | yes |
Dimension | 192mm*192mm |
Led Package | smd led |
Drive Ic | sm 16 series |
Protection | ip 67 |
Module Size | 192mm*192mm |
product Details
OUTDOOR P6 SMD 3IN1 TECHNICAL PARAMETERS | ||
Unit Module | Item | Parameter |
Model Number | P6-8S | |
Module size | 192mm*192mm | |
Pixel pitch | 6mm | |
Pixels Density | 27777dots/SQM | |
Pixel configuration | 1R1G1B | |
Package mode | SMD2727 | |
Pixel resolution | 32dots(W)*32dots(H) | |
Max Power | 35W | |
Module thickness | 17.05mm | |
Weight | 0.369kg | |
Drive type | Constant drive | |
Scan mode | 1/8scan | |
Port type | HUB75-A | |
Brightness of white balance | ≥6500cd/SQM | |
Cabinet | Dimension | 576mm*576mm |
Monomer Module Number | 9pcs | |
Power supply | 5V/40A*2 pcs | |
Thermal discharge | fan 1pcs | |
Pixel per cabinet | 96mm*96mm | |
Best viewing distance | 6M~40M | |
Best viewing angle | 160°(W) 120°(H) | |
Temperature | storage:-35???~+85??? | |
working:-20???~+50??? | ||
>9000hours | ||
Power switch | Automatic switch | |
Display Mode | ≥800*600/1024*768 |
Product Description
1. Small pixel pitch series, ultra high definition LED display, the high resolution brings delicate display effect.
2. Wide color range, excellent color uniformity, no rainbow effect, broadcasting strong stability.
Finished Products
Additional Information:
Product Details:
Type | smd |
Color | Full color |
Usage/Application | outdoor/ indoor |
Brand | qiangli |
Model Name/Number | p6 |
Body Material | plastic |
Warranty | 3 years |
IP Rating | ip67 |
Waterproof | yes |
Product Details:
Type | smd |
Color | Full color |
Usage/Application | video |
Brand | qiangli |
Model Name/Number | p8 |
Body Material | pvc |
Power | 100 watt |
Warranty | 3 years |
IP Rating | ip67 |
Brightness | 5000 |
Product Details:
Minimum Order Quantity | 01 Piece |
Type | smd |
Color | Full color |
Usage/Application | indoor |
Brand | qiangli |
Power | 10 watt |
Warranty | 3 years |
IP Rating | ip65 |
Waterproof | yes |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Dimension | 192mm*192mm |
Resolution | 64*64 |
Display Type | smd |
Warranty | 3 Years |
Brand | qiangli |
Pixel Density | 32*32 |
Shape | Rectangle |
Additional Information:
Product Details:
Brightness | 6500 |
Module size | 320mm*160mm |
Best Viewing Distance | 10 m |
Maximum Power Consumption | 100 watt |
Certification | bis |
Product Details:
Minimum Order Quantity | 01 Piece |
Maximum Operating Supply Voltage | 240 volts |
Maximum Operating Temperature | -20 To +60 |
Package Type | box |
Brand | novastar |
weight | 2.5 kg |
product type | video controller |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Usage/Application | video application |
Display Type | smd |
Voltage | 5 V DC |
Model Name/Number | msd 300 |
Power | 230 V AC |
Body Material | metal |
Display Function | video |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Part Number | tb2 |
Maximum Operating Supply Voltage | 240 |
Maximum Operating Temperature | -20 TO +60 |
Package Type | box |
Brand | nova star |
weight | 1300 gram |
Features :
If the user has a high demand on synchronization, the time synchronization module is recommended. For details, please consult our technical staff.In addition to solution publishing and screen control via PC, mobile phones and LAN, the comprehensive control plans also support remote centralized publishing and monitoring.For Ethernet port redundancy, 2 master and 2 backup Ethernet ports are provided.
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Usage/Application | Drive video wall |
Display Type | smd |
Color | Full color |
Voltage | 5 V DC |
Model Name/Number | mrv 328 |
Power | 230 V AC |
Time Delay | <10 s |
Display Function | video |
Memory | 8 gb |
Software | nova star |
Temperature Range | -20 To +60 |
Warranty | 3 years |
Additional Information:
Product Details:
Input Voltage Range | 240 |
Usage/Application | video wall smps |
Brand | G-energy |
Output Voltage | 5v |
Efficiency | 99% |
Input Voltage | 240 volts |
Design | Smps |
Display Type | LED |
Product Details:
Minimum Order Quantity | 01 Piece |
Material | Die-cast |
Lighting Type | king light |
Shape | Rectangular |
Color | Full color |
Letter Type | variable |
Power | Ac 220 volts |
Type | Indoor Type |
Usage/Application | Advertising |
Brand | pixel |
Operating Temperature | -20 To +80 |
Waterproof | yess |
Board Type | Indoor |
Power Source | Ac |
Voltage | 5v |
Operating Temp | -20 To+80 |
Weight | 0.5 kg |
Is It Folded | Non Folded |
Led Life Span | 100000 hours |
Mounted | smd mounting |
Dimension | customized |
I Deal In | New Only |
Retro Reflective | No |
Rustproof | Yes |
1.Our Service
1)Your inquiry related to our products or price will be replied in 24hrs
2)OEM&ODM,any your customized lightings we can help you to design and put into product
3)Distributoership are offered for your unique design and some our current models
4)Protection of your sales area,ideas of design and all your private information
5)Top Quality+Reasonable Price+Responsible After Service=Successful & Win
2.Trade Terms
1.Payment:T/T,30% deposits before production,70% balance to be paid before dleiverying
2.Shipping freight are quoted under your requests
3.Module Specification
module parameters | |
Model | P5 |
Pixel pitch | 5 mm |
Pixel configuration | 1R1G1B |
LED lamp | SMD 3 in 1 |
Module size | 320mm*160mm |
Module resolution rate | 64*32=2048dots |
Module dimensions (W*H*D) | 256*128*14.1mm |
Weight | 0.25kg±0.05kg |
Input votage | 4.8-5.5V |
MAX. input current | 6.8A±0.1A |
Driving mode | 1/16 scan, constant current |
cabinet parameters | |
Brightness | ≥1000 cd/m2 |
Cabinet dimensions (W×H×D) | 512*512*55 mm |
Resolution ratio | 128*128=16384dots |
Weight | 7.1±0.05 kg |
Pixel density | 62500dots/m2 |
Viewing angle (H/V) | 120±10 deg |
Best viewing distance | ≥4m |
MAX. power | ≤400W/m2 |
AVE. power | 200W/m2 |
control parameters | |
Gray scale per color | 12-16bits for red,green,blue |
Colors | 16777216 |
Life time | ≥100,000 hours |
Refresh rate | ≥ 500Hz |
Input voltage (AC) | 110V ~ 240V |
Operating temperature | -20°C ~+ 50°C |
Source compatibility (with video processor) | DVI/VGA,Vedio(mutiple modes),RGBHV,composite Vedio Single,S-VIDEO,YpbPr(HDTV) |
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Color | Full |
Power | Ac |
Voltage | Ac 220 volts |
Type | Indoor Type |
Shape | Rectangle |
Lighting Type | LED, Halogen, Flourescent, Incandascent, High Intensity Discharge |
Text Color | Full Colour |
Active Screen Dimensions | customized |
Usage/Application | Advertisements |
Operational Temperature | -20 To +60 |
Brand | king light |
Brightness | 1400 cd/m2 |
Led Configuration | smd 2121 |
Led Lifetime | 100000 hours |
Display Technology | Square Matrix, Dot Matrix |
Waterproof | yes |
Model Name/Number | p2.5 |
Operation Power Voltage | 220 |
Viewing Angle | 140 |
Connectivity | Ethernet, DSL/Cable Modem, Wi-Fi, RS485, Radio Frequency, Fiber Optics |
Frequency | 60 Hz |
Dimension | customized |
Humidity | 90-100% |
Warranty | 3 Years |
Led Package | smd 2121 |
Font Styles Supported | Bold, Italic |
Language Supported | Gujarati, English, Tamil, Malayalam, Urdu, Hindi, Punjabi, Telugu |
Drive Ic | mbi2121 |
IP Rating | IP 67 |
Lamp | king light |
Lifespan | 100000 hours |
Body Material | Aluminum |
Scan Mode | 1/2 scan |
Kinglight SMD2121 Indoor full color P2.5 LED Display Module for HD advertising
Item | Parameter |
Pixel Pitch | 2.5 mm |
LED Type | SMD2121 |
Configuration | 1R1G1B |
Module Size | 160*160 mm |
Pixel Density | 160000 pixel/??? |
Driving IC | MBI5124 |
Refresh Rate | ≥ 1920Hz |
Gray Scale | 16 Bit |
Brightness | ≥ 1000 cd/??? |
Best viewing distance | 2M~20M |
Scan Way | 1/32Scan |
Frame Rate | 50HZ~60HZ |
Viewing Angle | H:140°, V:140° |
Max.Power Consumption | 370W/??? |
Avg.Power Consumption | 1000W/??? |
Control System | Nova/Linsn/Dbstar |
Operation System | Windows XP/7/10 |
Working-Temperature | -20???~60??? |
Working Humidity | 10%~90% RH |
Input Voltage | AC 110~220 V |
Blind spot rate | ≤0.01% |
MTBF | 50000 Hour |
Lifespan | 100000 Hour |
Kinglight SMD2121 Indoor full color P2.5 LED Display Module for HD advertising
1.P2.5 indoor LED modules, with the date&power cables;
2.LED modules can work with Nova, Linsn, Colorlight,Xixun LED Conrol Card ,etc.
3. High precision module suite, to achieve high-quality seamless effect.
4. High quality LED lamp black, with a black mask, the contrast up to 3000: 1.
5.High gray,up to 16bit gray scale in low-light display gray scale performance is still intact.
6.High refresh rate,the display is stable, no ripples, no flicker, display real and natural.
7.Long life for 100,000 hours, brightness decay to half the life expectancy of up to 50,000 hours;
8.The products based on CE, FCC,ROHS Certification.
160*160mm P2.5 Indoor Full Color LED Display Module
Additional Information:
Product Details:
Minimum Order Quantity | 01 Piece |
Color | Full color |
UART IN/OUT | input and output port for cascading devices |
voltage | 100-240 volts |
frequency | 50-60 hz |
usb | types -b usb |
brand | nova star |
Additional Information:
